MARIN HEADLANDS 2

ADVENTURE ON AND OFF-ROAD RIDING

LONG DISTANCE COMMUTING

GRAVEL RIDING

The Headlands takes what we have learned with the alloy Gestalt X line, and brings the spirit to an all-new, full carbon fiber frameset. Modern geometry, generous tire clearance, and sublime ride quality, all combine to make an incredibly capable, lightweight bike that’ll exceed your expectations.

SPECIFICATIONS

• FRAME

  Unidirectional Carbon Beyond Road Platform, 1x Drivetrain Specific, 700c x 45mm/650B x 50mm Compatible, Flat Mount Disc, 142x12mm Thru-Axle, Internal Dropper Post Routing, Internal Housing Routing, Mudguard and Rear Carrier Mounting, Plentiful Gear Mounts

• FORK

  Marin Full Carbon w/ Tapered Steerer, 12mm Thru-Axle, Flat-Mount Disc, Fender Eyelets

• RIMS

  Marin Aluminum Double Wall, 21mm Inner, 21mm Tall, Disc Specific, Tubeless Compatible

• HUB, REAR

  Forged Aluminum Alloy, Disc, 28H

• HUB, FRONT

  Forged Aluminum Alloy, Disc, 28H

• SPOKE, NIPPLES NIPPLES

  Double Butted Stainless

• TIRES

  Vee Tire Co., G-Sport, 700cx44, Tubeless Compatible

• DERAILLEUR, REAR

  Shimano GRX RDX812 Shadow Plus w/ Clutch

• DERAILLEUR, FRONT

  -

• SHIFT LEVER

  Shimano GRX STX801, 1x11-Speed, Integrated Dropper Lever

• CRANKSET

  FSA Gossamer Pro, Megatooth 42T Chainring, BB386EVO Alloy Spindle

• BOTTOM BRACKET

  FSA MegaExo Threaded

• CHAIN

  KMC X11

• CASSETTE

  Shimano CSM8000, 11-Speed, 11/42T

• BRAKE, FRONT

  Shimano GRX Hydraulic Disc, 160mm Rotor

• BRAKE, REAR

  Shimano GRX Hydraulic Disc, 160mm Rotor

• BRAKE LEVERS

  Shimano GRX Hydraulic w/ Shifter and Integrated Dropper Lever

• HANDLEBAR

  Marin Butted Alloy, Compact 16º Flared Drop

• STEM

  Marin 3D Forged Alloy

• GRIPS

  Marin Shock Absorbing Tape

• HEADSET

  FSA Orbit IS, Sealed Cartridge Bearings, 1 1/8” x 1 1/2”

• SEATPOST

  TranzX YSP38 Dropper Post, 70mm/105mm Travel, 27.2mm

• SADDLE

  Marin Beyond Road Concept Elite

• PEDALS

  -

• EXTRAS

  Bolt-On Thru-Axles F and R

Specifications, pricing, and availability are subject to change without notice.
